mining lamp
This industrial high bay is efficient, energy-saving and environmentally friendly, and is widely used in various scenarios.
Power
100/150/200W
Efficacy
145-155Lm/W
IP Rating
IP65-IP66
Product Introduction
This industrial high bay is efficient, energy-saving and environmentally friendly, and is widely used in various scenarios. The luminaire uses a high-performance industrial power supply with full-voltage input, high PF and low THD, and complies with the EMC requirements of national standards. It offers 6KV surge immunity, adapting to the electromagnetic environment of various harsh industrial applications. The high colour-rendering chip creates a safe and comfortable working environment. The base version uses a direct hook-mount structure for out-of-the-box installation.
Product Features
- Precise light distribution: Optical lens with up to 96% light transmittance delivers even, soft light and higher optical efficiency.
- High safety: The light-emitting surface is covered by a one-piece lens (glass), improving protection reliability and safety in use.
- Long-term use: 50,000-hour lifespan guarantee (using first-tier international brand chips).
Main Application
Mainly applied to industrial plants, warehouses, waiting/boarding halls, exhibition centres, sports venues, etc.
Technical Specifications
| Model number | XYX218G5-100W / XYX218G5-150W / XYX218G5-200W |
| Power | 100W / 150W / 200W |
| Size | Ø242*165mm, Ø289*165mm, Ø328*165mm, Ø346*263mm, Ø400*263mm, Ø438*263mm |
| Input voltage | AC100V-277V 50/60Hz |
| Drive power supply | Mingwei, Philips, Maoshuo, Infineon, Xinzhaoyang |
| Chip configuration | SMD2835 |
| Colour rendering | Ra≥80 |
| Luminous efficiency | 145-155Lm/W |
| Colour temperature | 4000K / 5000K / 6500K |
| Lamp body material | Aluminium die casting |
| Protection level | IP65-IP66 |
| Installation height | 4m-15m |
| Installation method | Hooks, suspension rods |
